Acoustic Sound Barrier (BLACK)
Acoustic Sound Barrier is a dense, limp-mass vinyl material that is used to stop the transmission of sound in a wall stack-up
of materials. It acts as a thin, dense sound barrier layer in walls, ceilings or floors and is most effective when used as one
component of a multi-layered construction scheme.
Acoustic Sound Barrier is useful for decoupling (i.e. floating) floors and walls in isolation construction applications.
Applications:
Acoustic Sound Barrier can be widely used in residential homes and public places such as disco
ballrooms, gymnasiums, factory workshops, home cinemas, hotel lobby, hospital, shopping mall,
school, piano room, conference room, studio, recording room, bars, industrial plants, room, etc.
The mass loaded vinyl sound proofing can hugely reduce noise coming from vibration.
Features and Benefits:
Over 95% Recycled material
Optimized density and resiliency
Efficient spring action
Low compressibility
No creep or long term degradation
Strength under load
Effective impact noise reduction
Environmentally friendly
Low odor
Long life
Can be used together with Geowool or Mandi acoustic board (wall isolation)
Urethane as Binder
Technical Information for Acoustic Sound Barrier (BLACK):
• Width: 1.37m
• Thickness: 3mm
• Intended Use: Sound blocking
• Colour: Black (smooth on one side, has a pebble grain finish on the other side)
• STC: 26
| Sound Transmission Loss (dB) Per Octave Band (Hz) |
| Thickness |
125Hz |
250Hz |
500Hz |
1KHz |
2KHz |
4KHz
|
STC |
| 3mm |
14 |
19 |
23 |
28 |
33 |
37
|
26 |
